Sense 15 speaker
Archive

Brand
The SENSE SERIES by American Audio is a multifunctional, compact and lightweight speaker system for flexible yet ambitious sound applications. The HF cabinets` asymmetric design allows for both FoH and monitor usage. The passive crossovers are fine-tuned for optimum acoustics and excellent dynamics and have been developed using complex frequency curves and delays. In combination with latest amp-technology and the new LSM speaker management system the SENSE...
Read More

Product Information

SKU: 1162250002
GTIN: 819730017543
HS-Code: 8518220090

The SENSE SERIES by American Audio is a multifunctional, compact and lightweight speaker system for flexible yet ambitious sound applications.

The HF cabinets` asymmetric design allows for both FoH and monitor usage.

The passive crossovers are fine-tuned for optimum acoustics and excellent dynamics and have been developed using complex frequency curves and delays.

In combination with latest amp-technology and the new LSM speaker management system the SENSE SERIES is flexible enough to meet all your high-end requirements.

Gallery

Specification

  • - Woofer: 15” AA PA1575, aluminum basket, 75mm voicecoil - High Driver: 1” compression driver with 44mm (1.75”) voicecoil on a 75°x50° CD horn - Power Handling: 400W continous 800W program 1600W peak - Recommended input power: 300-600W an 8Ohm - Sensitivity: 98dB SPLmax. 129dB Peak - Freq. response (-3dB): 52Hz - 20kHz - Freq. range(-10dB): 42Hz - 21kHz - Nom. dispersion h x v (-6dB): 75°x50° - Impedance: 8Ohm - X-Over: 1800 Hz 12dB/18dB - Finish: black structure paint - Protective Grid: powder coated steel grill acoustic foam - Connector: 2x NL4 Speaker - Handle: 1 handle on the top - Monitor angle: 45° - Pole mount: integrated, M8 Screws for rigging eyes in all corners - Cabinet: plywood - Dimensions (LxWxH): 430x678x370mm - Weight: 22kg
  • FEATURE OVERVIEW - Perfect matched components and case details - Passive full range system for medium size applications - Multifunctional case design - Quadratic horn (rotatable) - 75° x 50° dispersion - First class mechanical manufacture for day-to-day operations - Equipped with optimized 15” MF/LF driver - Large optional accessory range - Ideal for mobile and install applications

Downloads

User Manual

Sense 15 speaker User Manual
(Size: 637.3 KB)
