Q-SD Record Archive
The American Audio Q-SD REC is the perfect combination of a DJ mixer, a SD-Card Player and a recording unit. Everything the DJ of today needs, built in one unit.
Product Information
The American Audio Q-SD REC is the perfect combination of a DJ mixer, a SD-Card Player and a recording unit. Everything the DJ of today needs, built in one unit.
Gallery
Specification
SPECIFICATIONS MIXER
- 4-channel, 19-inch Professional SD DJ mixer
- 2 Phono, 4 Line, 4 Aux & 2 Mic inputs
- Crossfader start control for CD player
- Mic input and master output trim control
- Fader Q Start compatible
- Balanced XLR outputs
- 2 DJ microphones with volume, treble, bass
- Gain, treble, mid & bass control for each channel (-26 dB Rotary Kills)
- Recessed back panel
- Mini plug input on face of mixer for use with MP3 players (standard 3.5mm plug)
- Headphone jack on face of mixer
- Cue mixing, cue level and master level control
- Zone output control
- Stream Flow LED indicators
- Trim output adjustment on rear
- Mic attenuator control on rear panel
SPECIFICATIONS SD-CARD PLAYER/RECORDER
- SD-/SDHC card slot for full functioning MP3 player and Recorder (128, 192, 256 Kbps MP3)
- Folder & Track knob selector
- Big LCD display with back-light
- Tempo Lock
- Advance MP3 Track Selection
- Antishock
- Auto BPM
- Time Function
- ID3 Tag Display
- Seamless Loop
- Auto BPM counter
- Pitch Blend (+/-4%, +/-8%, +/-16%)
STANDARD SPECIFICATIONS
- Power: AC 115/230V, 60/50Hz, 18W
- Dimensions (LxWxH): 483x177x110mm
- Weight: 3,8kg
