Pixie Driver 2000 V2 is designed specifically for the ADJ Pixie Strip 30, Pixie Strip 60, and Pixie Strip 120. It provides easy and versatile control options including simple on-board manual dimming and strobe control, plus full pixel mapping control of 2,040 max pixels via Kling-Net, Art-Net or sACN (streaming ACN) protocols.   The Pixie Driver 2000 V2 features a universal auto switching power supply (100-240V), a 4-button LCD control menu display, RJ45...
Read More

Product Information

SKU: 1226200065
GTIN: 810087370107
HS-Code: 8537109899
Pixie Driver 2000 V2 is designed specifically for the ADJ Pixie Strip 30, Pixie Strip 60, and Pixie Strip 120. It provides easy and versatile control options including simple on-board manual dimming and strobe control, plus full pixel mapping control of 2,040 max pixels via Kling-Net, Art-Net or sACN (streaming ACN) protocols.

The Pixie Driver 2000 V2 features a universal auto switching power supply (100-240V), a 4-button LCD control menu display, RJ45 Ethernet in/out ports, and (2) outputs which use proprietary, 4-pin combo cables (sold separately) that supply power and data to each pixel strip (available in lengths from 30 cm to 15 m). The Pixie Driver 2000 can be mounted in a standard 19-inch rack (rack ears included) or attached to truss with a clamp (not included). There is a USB port on the front panel to easily make updates to the firmware.

Gallery

Specification

  • • Power / data supply for ADJ Lighting Pixie Strip 30, Pixie Strip 60, and Pixie Strip 120
  • • Manual RGB mode
  • • Internal programs
  • • Manual Dimming and Strobe Control
  • • Full Pixel Mapping Control
  • • 2,040 Pixels via Kling-Net, Art-Net and sACN (streaming ACN)
  • • OLED screen with 4-button menu
  • • USB port for Firmware Updates

  • • 1020 pixels max each port (34 Pixie Strip 30; 17 Pixie Strip 60; 8 Pixie Strip 120)

  • • Power: Locking Power Input
  • • Two KlingNet / Artnet ethernet ports
  • • Two 4-pin DC24V power/data outputs to Pixie Strips

  • • Bolt to add a clamp to hang from truss (clamp and truss not included)
  • • Includes 19-inch rack mount ears
  • • Safety eye

  • • Multi-voltage operation: AC 100-240V, 50/60Hz
  • • Power Consumption: 400W max
  • • -20°C to 45°C

  • • Dimensions (LxWxH): 480x180.8x74mm
  • • Weight: 2.5 kg.

  • • PowerLock power cable
  • • 19-inch rack mount ears
  • • 4-pin data cable

Downloads

Additional Downloads

Pixie Driver 2000 V2 Pixie Driver 2000 V2 Output Limitiations (Size: 220.3 KB)

User Manual

Pixie Driver 2000 V2 User Manual
(Size: 1.5 MB)
