Lightning COB CANNON
Archive

Brand
The ADJ Lightning COB Cannon produces a large wash of white light from high output, advanced COB (Chip On Board) cool white LEDs–COB LED technology allowing for a powerful LED engine to be placed in a small amount of space. This professional lighting fixture is designed for washing performance stages, theatrical productions and special effects productions. It requires very little maintenance or service due to its sold state electronics. The Lightning COB Cannon has 3...
Read More

Product Information

SKU: 1215200025
GTIN: 819730010872
HS-Code: 9405409989

The ADJ Lightning COB Cannon produces a large wash of white light from high output, advanced COB (Chip On Board) cool white LEDs–COB LED technology allowing for a powerful LED engine to be placed in a small amount of space.

This professional lighting fixture is designed for washing performance stages, theatrical productions and special effects productions. It requires very little maintenance or service due to its sold state electronics.

The Lightning COB Cannon has 3 operational modes (sound active, manual or DMX), has 3 DMX operational modes, 5 selectable dim curves, a 4-Button DMX Display and is flicker free for film and television. This fixture is DMX linkable via 3-pin DMX, and is power linkable via Locking Power connections. The light source is a 100-Watt COB (Chip On Board) Cool White (8,000K) LED engine.




Gallery

Specification

    Specification:
    - Super Bright, high output, white strobe cannon
    - Great for performance stages, theatrical productions and special effects productions
    -requires almost no maintenance – low heat, low power consumption
    - Advanced COB Technology (Chip On Board) produces powerful, high output white light
    - 3 Operation modes: Sound Active, Manual, & DMX
    - 3 DMX Operation modes: 1, 2 & 3 channel
    - 4-button digital display
    - Flicker Free operation (No flickering on camera)
    - 5 selectable Dim Curves (Standard, Stage, TV, Architectural & Theatre)
    - LED pulse and strobe effect
    - Electronic Dimming: 0 - 100%
    - Beam angle: 33 degrees
    - Dual yoke allows fixture to be hung or set on the ground
    - DMX Linkable: 3-pin XLR data connectors
    - Power Linkable: Locking Power connectors (Up to 3 UV COB Cannon’s @ 120V, 5 UV COB Cannon’s @ 220V fixtures)
    - Long Life LEDs (Rated at approximately 25,000 hrs.)
    - Power Draw: 120W total (All LED's @ Full)
    - Light Source: 100W COB (Chip On Board) cool white (8,000K) LED engine
    - Multi-voltage Operation: Auto switching, AC 100V - 240V/50Hz -60Hz
    - Dimensions (LxWxH): 12.75” x 11” x 8”/ 320 x 278 x 200mm
    - Weight: 11 lbs. / 4.98kgs

    Specifications subject to change without notice

    Videos

    Downloads

    Photometric Data

    Lightning COB CANNON Lightning COB Cannon Photometrics (Size: 668.9 KB)

    Photometric IES File

    Lightning COB CANNON Lightnng COB Cannon Photometric IES Files (Size: 2.1 KB)

    User Manual

    Lightning COB CANNON User Manual
    (Size: 55.4 KB)
